Figure 1. Human Pancreatic Duct Organoids

PancreaCult™ Organoid Initiation Medium (OIM; Human) and Organoid Growth Medium (OGM; Human) support the initiation and expansion of human pancreatic duct organoids from pancreatic tissue or previously established organoid cultures. Shown are organoids grown using PancreaCult™ OIM and OGM and imaged on day 7 of passage 3.

Figure 2. PancreaCult™ Human Enables Initiation and Expansion of Pancreatic Ductal Organoids

Human pancreatic ductal organoids are initiated in PancreaCult™ OIM for the first 3 days of culture, then switched to PancreaCult™ OGM for the remainder of culture. Alternatively, organoids can be grown in PancreaCult™ OGM for a completely serum-free protocol, however, proliferative pancreatic ductal cells are better supported in PancreaCult™ OIM during the first 3 days of culture. Cultures should be passaged after 7 days with further medium changes every 2-3 days. Pancreatic ductal organoids are suitable for experimentation or banking after one full passage in PancreaCult™ OGM. For full culture instructions please refer to the product manual (Document #10000011617)

Figure 3. PancreaCult™ (Human) Provides Robust Expansion of Pancreatic Duct Organoids

(A) Organoid expansion in PancreaCult™ OGM provides robust expansion of organoids across different donors. (B) Organoids may be initiated in PancreaCult™ OGM for a completely serum-free workflow, however, initiation and maintenance of damaged tissue is better supported by initiating cultures in PancreaCult™ OIM. (C) Comparison of PancreaCult™ Human to two different DIY formulations showed more robust expansion of organoids in PancreaCult™ Human. Shown is the cumulative fold expansion of organoid fragments as counted at the end of each passage.

Figure 4. Pancreatic Duct Organoids Display Features of the Pancreatic Ductal Epithelium

Organoids grown using the PancreaCult™ (Human) display marker expression consistent with the pancreatic ductal epithelium when imaged using immunocytochemistry. Shown are organoids grown in PancreaCult™ OGM and stained for (A) pancreatic ductal marker CK19, (B) pancreatic ductal marker SOX9, (C) epithelial marker EPCAM, (D) proliferation marker KI67, (E) apical pancreatic duct marker MUC1, and (F) pancreatic ductal marker CA2. Organoids were imaged on passage 2 (A), passage 3 (B, C) or passage 10 (D-F).

Figure 5. Pancreatic Duct Organoids Cultured With PancreaCult™ Human Show Pancreatic Marker Expression Levels Similar to Exocrine Tissue

Pancreatic duct organoids grown using the PancreaCult™ Human show marker expression levels similar to those observed in exocrine tissue. Analysis by qPCR showed pancreatic duct organoids were enriched for (A) PDX1 (C) CK19 and (F) LGR5 as compared to total pancreatic tissue, demonstrating enrichment of proliferative duct organoids. Comparable expression of (B) SOX9, (D) cystic fibrosis transmembrane receptor (CFTR), and (E) CA2 was observed in pancreatic duct organoids. Expression levels are normalized to TBP and UBC housekeeping genes (ΔCT) and total pancreas for relative expression levels (ΔΔCT).
