Anti-Mouse CD45 Antibody, Clone 30-F11

Rat monoclonal IgG2b antibody against mouse CD45

概要

技术资料

数据及文献

概要

The 30-F11 antibody reacts with an extracellular epitope found on all isoforms and both alloantigens (CD45.1 and CD45.2) of mouse CD45, a type I transmembrane glycoprotein expressed on the surface of most hematopoietic cells except mature erythrocytes, platelets and plasma cells; expression of CD45 is lost during differentiation of these cell types. CD45 is a member of the protein tyrosine phosphatase family and functions in a number of immunoregulatory processes, including cell activation, growth, differentiation and oncogenic transformation. The large cytoplasmic portion of CD45 contains two tyrosine phosphatase domains, one which is enzymatically active, that are involved in modulating the function of intracellular substrates such as the Src kinases Lck and Fyn. Several isoforms of CD45 have been identified, the expression of which differs according to cell type and functional status. Alternative splicing of three exons (4, 5, 6) encoding the extracellular RA, RB and RC polypeptide sequences gives rise to up to 8 isoforms with molecular masses in the range of 180 - 240 kDa.

技术资料

Document Type	产品名称	Catalog #	Lot #	语言
Product Information Sheet	Anti-Mouse CD45 Antibody, Clone 30-F11	60030, 60030.1	All	English
Product Information Sheet	Anti-Mouse CD45 Antibody, Clone 30-F11, Alexa Fluor® 488	60030AD, 60030AD.1	All	English
Product Information Sheet	Anti-Mouse CD45 Antibody, Clone 30-F11, APC	60030AZ, 60030AZ.1	All	English
Product Information Sheet	Anti-Mouse CD45 Antibody, Clone 30-F11, Biotin	60030BT, 60030BT.1	All	English
Product Information Sheet	Anti-Mouse CD45 Antibody, Clone 30-F11, FITC	60030FI, 60030FI.1	All	English
Product Information Sheet	Anti-Mouse CD45 Antibody, Clone 30-F11, PE	60030PE, 60030PE.1	All	English
Product Information Sheet	Anti-Mouse CD45 Antibody, Clone 30-F11, PerCP-Cy5.5	60030PS, 60030PS.1	All	English
Safety Data Sheet	Anti-Mouse CD45 Antibody, Clone 30-F11	60030, 60030.1	All	English
Safety Data Sheet	Anti-Mouse CD45 Antibody, Clone 30-F11, Alexa Fluor® 488	60030AD, 60030AD.1	All	English
Safety Data Sheet	Anti-Mouse CD45 Antibody, Clone 30-F11, APC	60030AZ, 60030AZ.1	All	English
Safety Data Sheet	Anti-Mouse CD45 Antibody, Clone 30-F11, Biotin	60030BT, 60030BT.1	All	English
Safety Data Sheet	Anti-Mouse CD45 Antibody, Clone 30-F11, FITC	60030FI, 60030FI.1	All	English
Safety Data Sheet	Anti-Mouse CD45 Antibody, Clone 30-F11, PE	60030PE, 60030PE.1	All	English
Safety Data Sheet	Anti-Mouse CD45 Antibody, Clone 30-F11, PerCP-Cy5.5	60030PS, 60030PS.1	All	English

数据及文献

Data

Figure 1. Data for Unconjugated

Flow cytometry analysis of C57BL/6 mouse splenocytes labeled with Anti-Mouse CD45 Antibody, Clone 30-F11, followed by a mouse anti-rat IgG2b antibody, FITC (filled histogram), or Rat IgG2b, kappa Isotype Control Antibody, Clone RTK4530 (Catalog #60077), followed by a mouse anti-rat IgG2b antibody, FITC (solid line histogram).

Figure 2. Data for Alexa Fluor® 488-Conjugated

Flow cytometry analysis of C57BL/6 mouse splenocytes labeled with Anti-Mouse CD45 Antibody, Clone 30-F11, Alexa Fluor® 488 (filled histogram) or Rat IgG2b, kappa Isotype Control Antibody, Clone RTK4530, Alexa Fluor® 488 (Catalog #60077AD) (solid line histogram).

Figure 3. Data for APC-Conjugated

Flow cytometry analysis of C57BL/6 mouse splenocytes labeled with Anti-Mouse CD45 Antibody, Clone 30-F11, APC (filled histogram) or Rat IgG2b, kappa Isotype Control Antibody, Clone RTK4530, APC (Catalog #60077AZ) (solid line histogram).

Figure 4. Data for Biotin-Conjugated

Flow cytometry analysis of C57BL/6 mouse splenocytes labeled with Anti-Mouse CD45 Antibody, Clone 30-F11, Biotin, followed by streptavidin (SAV) APC (filled histogram), or Rat IgG2b, kappa Isotype Control Antibody, Clone RTK4530, Biotin (Catalog #60077BT), followed by SAV APC (solid line histogram).

Figure 5. Data for FITC-Conjugated

Flow cytometry analysis of C57BL/6 mouse splenocytes labeled with Anti-Mouse CD45 Antibody, Clone 30-F11, FITC (filled histogram) or Rat IgG2b, kappa Isotype Control Antibody, Clone RTK4530, FITC (Catalog #60077FI) (solid line histogram).

Figure 6. Data for PE-Conjugated

Flow cytometry analysis of C57BL/6 mouse splenocytes labeled with Anti-Mouse CD45 Antibody, Clone 30-F11, PE (filled histogram) or Rat IgG2b, kappa Isotype Control Antibody, Clone RTK4530, PE (Catalog #60077PE) (solid line histogram).

Figure 7. Data for PerCP-Cy55-Conjugated

Flow cytometry analysis of C57BL/6 mouse splenocytes labeled with Anti-Mouse CD45 Antibody, Clone 30-F11, PerCP-Cy5.5 (filled histogram) or a rat IgG2b, kappa PerCP-Cy5.5 isotype control antibody (solid line histogram).
