Anti-Mouse CD44 Antibody, Clone IM7

Rat monoclonal IgG2b antibody against human, mouse, rhesus CD44 (tissue non-specific alkaline phosphatase)

概要

技术资料

数据及文献

概要

The IM7 antibody reacts with CD44 (Ly-24), an ~80 - 95 kDa type 1 transmembrane glycoprotein involved in cell-cell and cell-matrix interactions. CD44 is expressed on the surface of many cells, including leukocytes and hepatocytes, as well as endothelial, epithelial, and mesenchymal cells. Expression levels increase upon activation of T and B cells, and memory cells exhibit a CD44high phenotype. CD44 binds many ligands, including hyaluronic acid, collagen, fibronectin, growth factors, and metalloproteinases, thus modulating processes such as lymphocyte activation, recirculation and homing, leukocyte rolling and aggregation, hematopoiesis, and tumor metastasis. Numerous disorders are associated with altered expression or dysfunction of CD44. Many CD44 isoforms have been identified, with alternative splicing, differential N- and O- glycosylation, and sulfation mediating the functional role(s) played by the protein in a specific cell. The IM7 monoclonal antibody reacts with an extracellular epitope found on all isoforms of CD44 and both murine allotypes.

This antibody clone has been verified for purity assessments of cells isolated with EasySep™ kits, including EasySep™ Mouse CD4+ T Cell Isolation Kit (Catalog #19852), EasySep™ Mouse CD4+CD62L+ T Cell Isolation Kit (Catalog #18765), and EasySep™ Human Naïve CD4+ T Cell Isolation Kit (Catalog #19555).

技术资料

Document Type	产品名称	Catalog #	Lot #	语言
Product Information Sheet	Anti-Mouse CD44 Antibody, Clone IM7	60068, 60068.1	All	English
Product Information Sheet	Anti-Mouse CD44 Antibody, Clone IM7, Alexa Fluor® 488	60068AD, 60068AD.1	All	English
Product Information Sheet	Anti-Mouse CD44 Antibody, Clone IM7, APC	60068AZ, 60068AZ.1	All	English
Product Information Sheet	Anti-Mouse CD44 Antibody, Clone IM7, Biotin	60068BT, 60068BT.1	All	English
Product Information Sheet	Anti-Mouse CD44 Antibody, Clone IM7, FITC	60068FI, 60068FI.1	All	English
Product Information Sheet	Anti-Mouse CD44 Antibody, Clone IM7, PE	60068PE, 60068PE.1	All	English
Product Information Sheet	Anti-Mouse CD44 Antibody, Clone IM7, PerCP-Cy5.5	60068PS, 60068PS.1	All	English
Safety Data Sheet	Anti-Mouse CD44 Antibody, Clone IM7	60068, 60068.1	All	English
Safety Data Sheet	Anti-Mouse CD44 Antibody, Clone IM7, Alexa Fluor® 488	60068AD, 60068AD.1	All	English
Safety Data Sheet	Anti-Mouse CD44 Antibody, Clone IM7, APC	60068AZ, 60068AZ.1	All	English
Safety Data Sheet	Anti-Mouse CD44 Antibody, Clone IM7, Biotin	60068BT, 60068BT.1	All	English
Safety Data Sheet	Anti-Mouse CD44 Antibody, Clone IM7, FITC	60068FI, 60068FI.1	All	English
Safety Data Sheet	Anti-Mouse CD44 Antibody, Clone IM7, PE	60068PE, 60068PE.1	All	English
Safety Data Sheet	Anti-Mouse CD44 Antibody, Clone IM7, PerCP-Cy5.5	60068PS, 60068PS.1	All	English

数据及文献

Data

Figure 1. Data for Unconjugated

Flow cytometry analysis of human peripheral blood mononuclear cells (PBMCs; gated on lymphocytes) labeled with Anti-Mouse CD44 Antibody, Clone IM7, followed by Goat Anti-Mouse IgG (H+L) Antibody, Polyclonal, FITC (Catalog #60138FI) (filled histogram), or a rat IgG2b, kappa isotype control antibody, followed by Goat Anti-Mouse IgG (H+L) Antibody, Polyclonal, FITC (solid line histogram).

Figure 2. Data for Alexa Fluor® 488-Conjugated

(A) Flow cytometry analysis of C57BL/6 mouse splenocytes labeled with Anti-Mouse CD44 Antibody, Clone IM7, Alexa Fluor® 488 (filled histogram) or a rat IgG2b, kappa Alexa Fluor® 488 isotype control antibody (open histogram).
(B) Flow cytometry analysis of human peripheral blood mononuclear cells (PBMCs) labeled with Anti-Mouse CD44 Antibody, Clone IM7, Alexa Fluor® 488 (filled histogram) or a rat IgG2b, kappa Alexa Fluor® 488 isotype control antibody (open histogram).

Figure 3. Data for Biotin-Conjugated

(A) Flow cytometry analysis of C57BL/6 mouse splenocytes labeled with Anti-Mouse CD44 Antibody, Clone IM7, Biotin followed by streptavidin (SAV) APC (filled histogram) or a rat IgG2b, kappa Biotin isotype control antibody followed by SAV APC (solid line histogram).
(B) Flow cytometry analysis of human peripheral blood mononuclear cells (PBMCs) labeled with Anti-Mouse CD44 Antibody, Clone IM7, Biotin followed by streptavidin (SAV) APC (filled histogram) or a rat IgG2b, kappa Biotin isotype control antibodyfollowed by SAV APC (open histogram).

Figure 4. Data for PE-Conjugated

(A) Flow cytometry analysis of C57BL/6 mouse splenocytes labeled with Anti-Mouse CD44 Antibody, Clone IM7, PE (filled histogram) or a rat IgG2b, kappa PE isotype control antibody (open histogram).
(B) Flow cytometry analysis of human peripheral blood mononuclear cells (PBMCs) labeled with Anti-Mouse CD44 Antibody, Clone IM7, PE (filled histogram) or a rat IgG2b, kappa PE isotype control antibody (open histogram).

Figure 5. Data for PerCP-Cy55-Conjugated

Flow cytometry analysis of C57BL/6 mouse splenocytes labeled with Anti-Mouse CD44 Antibody, Clone IM7, PerCP-Cy5.5 (filled histogram) or a rat IgG2b, kappa isotype control antibody, PerCP-Cy5.5 (solid line histogram).

Figure 6. Data for FITC-Conjugated

Flow cytometry analysis of C57BL/6 mouse splenocytes labeled with Anti-Mouse CD44 Antibody, Clone IM7, FITC (filled histogram) or Rat IgG2b, kappa Isotype Control Antibody, Clone RTK4530, FITC (Catalog #60077FI) (solid line histogram).

Figure 7. Data for APC-Conjugated

Flow cytometry analysis of C57BL/6 mouse splenocytes labeled with Anti-Mouse CD44 Antibody, Clone IM7, APC (filled histogram) or Rat IgG2b, kappa Isotype Control Antibody, Clone RTK4530, APC (Catalog #60077AZ) (solid line histogram).

Publications (1)

Cell 2018 JAN Transmembrane Pickets Connect Cyto- and Pericellular Skeletons Forming Barriers to Receptor Engagement. Freeman SA et al.

Abstract

View publication

Abstract

Phagocytic receptors must diffuse laterally to become activated upon clustering by multivalent targets. Receptor diffusion, however, can be obstructed by transmembrane proteins (pickets") that are immobilized by interacting with the cortical cytoskeleton. The molecular identity of these pickets and their role in phagocytosis have not been defined. We used single-molecule tracking to study the interaction between Fcγ receptors and CD44 an abundant transmembrane protein capable of indirect association with F-actin hence likely to serve as a picket. CD44 tethers reversibly to formin-induced actin filaments curtailing receptor diffusion. Such linear filaments predominate in the trailing end of polarized macrophages where receptor mobility was minimal. Conversely receptors were most mobile at the leading edge where Arp2/3-driven actin branching predominates. CD44 binds hyaluronan anchoring a pericellular coat that also limits receptor displacement and obstructs access to phagocytic targets. Force must be applied to traverse the pericellular barrier enabling receptors to engage their targets.
